The handle is a DualShock 4 Bluetooth handle case applied to the PS4 host. The Bluetooth connection distance of the handle is more than 10M, and it adopts the civil exhibition scheme; it uses a new motion sensing technology, built-in three-axis gyroscope and three-axis accelerator. The 6-axis sensor function detects all-round dynamic information including Roll (left and right tilt), Pitch (front and rear tilt), and Yaw (left and right rotation). In addition to accurately sensing the tilt angle of the handle, it can also capture the three-dimensional space X, Y , Z, 3-axis acceleration information, and quickly transfer all the data to the game system, through this function, players can use the PS4 DualShock 4 handle, this innovative motion sensing technology, to play games with special operations. The DualShock 4 also adds brand new features, including a two-point capacitive-sensing trackpad that can be pressed on the front. The DualShock4 is also the first PC to officially support Windows. There are several built-in output connection ports in the handle, among which the 3.5mm TRRS stereo jack can be connected to headphones and microphones, allowing users to receive and transmit audio at the same time. The controller also features a Micro-USB port, an expansion port, and a mono speaker. The controller can be charged via mirco-USB or a dedicated charging stand.
The handle is also loaded with light bars that display various colors. Different colors can be used to represent different players, and can be used as a reminder of important information (such as the game character's health reduction, etc.). In addition, the light bar can also interact with the PlayStationCamera, allowing the camera to use the light bar to determine the movement and distance of the controller
1. The handle has stable performance and high cost performance, and supports any software version of the PS4 host;
2. The connection distance of the Bluetooth handle is more than 10M;
3. With 3D acceleration sensor and gyroscope sensor function, the 6-axis sensor function is composed;
4. With RGB LED color channel indication, it is convenient to distinguish different users and roles;
5. The Bluetooth connection mode is the same as the original handle mode;
6. Support USB lithium battery charging;
7. Support 3.5mm TRRS stereo jack to connect headphone and microphone, speaker output independently;
8. Support dual-point capacitive sensing touchpad;
9. Support dual motor vibration function, use pressure-sensitive motor;
Choose to use the standard PS4 function (the same as the original function, can work on the PC through the driver, Windows10 and Android 5.0 and above are free of driver)
Wide operating voltage range, ultra-low sleep current, operating voltage and current: 3.7V-80mA, USB input voltage and current: 5.2V-1000mA
This solution supports PC USB online upgrade of product programs, thus supporting the latest PS4 host upgrade system. It can effectively avoid the problem that the product cannot be used due to the host upgrade system
